Allwinner A527 / T527

General Specifications

Specs
SoCAllwinner A527 / T527
CPU8× Cortex-A55 (Armv8.2-A) @ 2 GHz
MemoryLPDDR4 / LPDDR4X
GPUMali-G57
Vendor: OpenGL ES 3.2, Vulkan 1.1, OpenCL 2.0
Mesa: OpenGL 3.1, OpenGL ES 3.1, OpenCL 3.0 (Panfrost, Rusticl, Panfrost kernel)
NPU2 TOPS
Supports INT8 / INT16 / FP16
T527 variant only
VPUDecode: 4K@60fps H.264, H.265, VP9
Encode: 1080p@60fps H.264, H.265

Linux Support

Mainline kernel

  • Fully supported
  • Works but not all features are implemented.

Documentation

  • Technical Reference Manual

Boards with A527

List of boards:
