Snapdragon 8cx Gen 3
General Specifications
Specs
| SoC | Snapdragon 8cx Gen 3 |
|---|---|
| CPU | 4x Arm Cortex-X1 up to 3.0 GHz 4x Arm Cortex-A78 up to 2.4 GHz - 64-bit - 5 nm process |
| RAM | LPDDR4X up to 4266 MT/s - 128-bit bus (8 channels, 16-bit per channel) - Up to 32GB |
| GPU | Adreno 690 - OpenGL ES 3.2 - Vulkan 1.3 - OpenCL 2.0 - DirectX - DirectML |
| VPU | Adreno VPU (5th generation) - Decode up to 4K120: H.265 Main 10, H.265 Main, H.264 High, VP9 Profile 2 - Encode up to 4K60: H.265 Main 10, H.265 Main, H.264 High |
| NPU | Qualcomm Hexagon processor and Sensing Hub - Qualcomm AI Engine up to 29+ TOPS |
Also known as:
- SC8280XP
- SA8540P
- SA8295P
Resources:
Linux Support
Mainline kernel
- Fully supported
- Works, but not every feature is implemented. Driver support matrix is here
Mesa GPU support
- Available with Freedreno (Adreno 690)
Windows on Arm Support
- Available but depends on the board vendor to provide a compatible bootloader
Boards with Snapdragon 8cx Gen 3
List of boards:
