QCS6490 / QCM6490 #

General Specifications #

Specs

SoC	QCS6490 / QCM6490
CPU	1x Kryo Gold plus (A78): high-performance core up to 2.7 GHz 3x Kryo Gold (A78): high-performance cores @ 2.4 GHz 4x Kryo Silver (A55): low-power cores @ 1.9 GHz - Designed with the 6 nm process
RAM	Dual-channel non-PoP high-speed memory, LPDDR5/LPDDR4x SDRAM - LPDDR5 SDRAM designed for 3200 MHz clock (2 x 16-bit) - LPDDR4X SDRAM designed for 2133 MHz clock (2 x 16-bit)
GPU	Adreno 643 GPU @ 812 MHz
VPU	- 4K@60fps decode for H.264/H.265/VP9 - 4K@30fps encode for H.264/H.265
NPU	6th gen Qualcomm® AI Engine: - Compute Hexagon DSP with dual Hexagon Vector eXtensions (HVX) - Hexagon Co-processor (Hexagon CP) 2.0 - Hexagon Tensor Accelerator
